case report

Indian Pediatr 2010;47: 440-442

Occipital Osteodiastasis


Sudhir Dixit, Ashish Jain, Suhas Datar and Nagendra Sinha

From the Neonatology Division, Department of Pediatrics, Hindu Rao Hospital, Delhi, India.

Correspondence to: Dr Ashish Jain, Neonatologist, Department of Pediatrics, Hindu Rao Hospital, Malka Gunj, Delhi, India.
Email: [email protected]

Received: November 19, 2008;
Initial review: December 18, 2008;
Accepted: March 12, 2009.




Abstract

There is no report of the use of antisnake venom (ASV) in the neonatal age group in literature. We report a 27 days old female neonate who presented with neuroparalytic manifestations of snake bite and was treated successfully with ASV. A total of 50 vials (500 mL) of polyvalent antisnake venom were given as infusion in hourly aliquots of 50 mL, over 72 hours.

Key words: Antisnake venom, Neonate, Neuroparalytic, Snake bite.


O
ccipital osteodiastasis (OOD) is an uncommon form of birth injury associated with posterior fossa subdural haemorrhage and laceration of cerebellum. The lesion consists of traumatic separation of the cartilaginous joint between the squamous and lateral portion of the occipital bone. Although birth asphyxia is the most common cause of neonatal death in India, birth injuries are rarely reported. We report a non-fatal case of ODD resulting from difficult breech extraction.

Case Report

A female baby weighing 2750 g was born by difficult breech extraction to a primigravida mother. Baby needed positive pressure ventilation for 60 seconds, and was transferred to neonatal intensive care unit for post-resuscitation care. There was no clinical evidence of hypoxic-ischemic encephalopathy. Tube feeding was started on second day of life and with breastfeeds were initiated on 4th postnatal day. However, she was observed to have poor sucking ability and breastfeeding sessions were relatively long, lasting more than 20 minutes. Physical examination revealed mild generalized hypotonia. Blood sugar, calcium and serum electrolytes were within normal range. Sepsis screen and blood culture were not suggestive of sepsis. Neurosonogram showed echogenic focus in the occipital horn. X-ray skull lateral view showed separation of squamous and lateral portion of occipital bone(Fig.1). Cranial CT scan revealed large extra axial bleed in the right temporo-parieto-occipetal region and both sides of tentorium cerebelli. Blood was also seen in the posterior inter-hemispheric fissure (Fig.2). Based on perinatal history and investigations a diagnosis of occipital osteodiastasis was made. The infant was managed conservatively and started accepting breastfeeds by 15th day of postnatal life. She was discharged on 20th day.

Fig. 1 X ray skull showing diastasis of occipital bones.



Fig. 2 CT Scan showing large extra-axial bleed on the right side (parieto-occipital region).

Discussion

Occipital bone is composed of four ossified parts around the foramen magnum: a squamous part, two laterals condylar parts and a basilar part. Squamous and lateral parts are separated by a strip of posterior intraoccipital cartilage. Ossification of this synchondrosis is completed during 4th or 5th year of life. The synchondrosis is vulnerable to injury during delivery. A tear along this point with separation of the occipital squama from the condylar parts is referred as occipital osteodiastasis. The injury is attributed to excessive pressure exerted over the subocciput resulting in a forward and upward displacement of anterior margin of the occipital squama into the posterior cranial fossa. This displacement may cause posterior fossa hemorrhage and other intracranial complications.

The clinical syndrome consists of three phases. In the first phase, no neurological signs are apparent for a period of several hours to 4 days after birth. Second phase is heralded with signs referable to increased intracranial pressure. Third phase has signs referable to brain stem disturbances(3). Depending on severity, OOD can have variable presentation. A fatal form associated with delivery has been described by Hemsath(1). Two additional cases similar to the fatal type but of postnatal origin (a three month old male and a two year old girl) have also been described by Currarino(2). With the advances in obstetrical techniques, this severe form of injury has become quite rare(2). Two more cases described(2) belong to less severe form of OOD, one of this case is associated with vertex presentation with an occipito-posterior position.

The present case was a less severe form of OOD, which is a rare. Wigglesworth(4,5) suggested that a minor separation of the occipital bone with little displacement would be without consequence. This form of OOD is rarely reported in literature. The first patient was reported by Pape, et al.(6) in 1979. Second case, reported by Roche, et al.(7) in 1990, was a term infant born by vaginal delivery to a 21 year old primipara. Later, two more similar cases were reported(2). Wigglesworth and Husemeyer(5) indicated that the diagnosis in stillborn babies may be facilitated by dissection of the sub-occipital region with incision of the atlanto-occipital membrane prior to opening the skull; also preliminary lateral X-rays help to demonstrate the lesion.

Severe OOD and its complications have been associated with poor outcome. Psychomotor development and neurological prognosis in survivors is reported to be favorable. Prognosis with convexity subdural haemorrhage is relatively good, from 50% to 90% of affected infants are well on follow up, others are left with focal cerebral signs and occasionally hydrocephalus. Close surveillance alone is required in the absence of major neurological signs(8).

Acknowledgment

Dr V Devgan, Head, Department of Paediatrics and Dr R B Mittal, Medical Superindentant: Hindu Rao Hospital, Delhi, for the permission to share this case; Dr Vishnu Goyal for help to draft this report.

Contributors: AJ made the diagnosis, was responsible for literature search. SD drafted and prepared the manuscript. SD critically evaluated the paper and gave the final approval. NS from radiology department helped confirm the diagnosis.

Funding: None.

Competing interests: None stated.

References

1. Hemsath FA . Birth injury of the occipital bone with a report of thirty-two cases. Am J Obstet Gynecol 1934; 27: 194-203.

2. Currarino G. Occipital Osteodiastasis: presentation of four cases and review of the literature. Pediatr Radiol 2000; 30: 823-829.

3. Volpe JJ. Intracranial hemorrhage; Subdural. Primary subarachnoid, Cerebellar, Intraventricular (term infant), and Miscellaneous. In: Volpe JJ. Neurology of the Newborn, 5th ed. Philadelphia: WB Saunders; 2009. p. 489-491.

4. Wigglesworth JS. Perinatal Pathology, 2nd edn. Philadelphia: Saunders; 1996. p. 92-93.

5. Wigglesworth JS, Husemeyer RP. Intracranial birth trauma in vaginal breech delivery: The continued importance of injury to the occipital bone. Br J Obstet Gynecol 1977; 84: 684-691.

6. Pape KE, Wigglesworth JS. Hemorrhage, ischemia and the perinatal brain. Philadelphia: JB Lippincott; 1979. p. 66-71.

7. Roche MC, Velez A, Garcia Sanchez P, Castroviejo P. Occipital osteodiastasis a rare complication in cephalic delivery. Acta Paediatr Scand 1990; 79: 380-382.

8. Perrin RG, Rutka JT, Drake JM, . Management and outcomes of posterior fossa subdural hematomas in neonates. Neurosurgery 1997; 40: 1190-1199.
